Overview
The XCTF-8405-C03 is a passive UHF RFID tag designed for superior performanceon a variety of surfaces particular on metal. Confirming to EPCglobal Class 1Gen 2 and ISO 18000-6C this tag shows unsurpassed UHF performance reliableoperation in dense reader environment and long read ranges.

TheXCTF-8405-C03 features an extended 512 bit programmable user memory 240 bit EPCnumber and a 64 bit tag identifier including a 32 bit unique serial number.This tag provides a unique custom command set such as Electronic ArticleSurveillance (EAS) for increased theft protection. All custom commands are 32bit access password protected.

Equippedwith a rugged design for the extreme harsh operating conditions theXCTF-8405-C03 is reusable for lower cost per use and offers a variety ofoptions including screws rivets and double-sided adhesive strips for ease ofinstallation. It is compatible with the complete portfolio of Invengo mobileand fixed RFID readers.

Features
EPCglobal Class 1 Gen 2 & ISO 18000-6C compliant
Operating frequency 902-928MHz
512-bit on-chip user memory
240-bit EPC number
64-bit tag identifier including 32-bit unique serial number
32-bit access password 32-bit kill password
Fastdata rate
Multi-tag operation
Longread range
Consistent performance on different materials
Reliable operation in multi-reader environment
Theft protection through EAS feature
Readprotection

Applications
Logistics
Asset tracking
Supply Chain

Physical Characteristics
Dimensions: 155 x 32 x 10mm (6.1 x 1.3 x 0.4in)
Base material: FR-4; copper
Case material: ABS plastics; PC plastics

UserEnvironment
Operating temperature: -20 to +70 (-4 to +158)
Storage temperature: -40
to +85 (-40 to +185)

PerformanceSpecifications
Operating frequency: 902-928MHz
Supported standard: EPCglobal Class 1 Gen 2; ISO 18000-6C
Read distance: Up to 10m / 32.8ft (reader dependent)
Chip type: UCODE G2 XM
Memory: 240-bit EPC; 64-bit TID; 512-bit programmable user memory
Functionality: Read / Write
Data retention:
10 years
